Current Transducers & Sensors

A variety of Current Transducers and RPM & Angle Sensors

current transducersDEWETRON offers several solutions for current measurement from simple shunts to current clamps and high-precision zero flux transducers. There are versions for pure AC current which do not need any power supply and versions for DC and AC current which can be supplied from the DEWETRON instrument. Have a look at the tables below.

You are looking for an RPM or angle sensor to complete your DAQ system for your demanding measurement task? Then have a look at our Tape Sensor and Tacho Probe below.

Current Transducers

CLAMP (AC/DC)
PDF NOMINAL
RMS [A]
SCALING
[mV/A]
BANDWIDTH
[kHz]
ACCURACY
[%]
INNER DIAMETER
[mm]
RECOMMENDED
INPUT MODULE
SE-CUR-CLAMP-20-DC Download the PDF here 20 100 1000 0.3 20 TRION(3)-18xx-POWER-4
+ SUB-CUR-dLV
SE-CUR-CLAMP-200-DC Download the PDF here 200 10 500 0.3 20 TRION(3)-18xx-POWER-4
+ SUB-CUR-dLV
SE-CUR-CLAMP-500-DC Download the PDF here 500 4 200 0.3 20 TRION(3)-18xx-POWER-4
+ SUB-CUR-dLV
SE-CUR-CLAMP-1000-DC-S Download the PDF here 1000 2 20 0.3 50 TRION(3)-18xx-POWER-4
+ SUB-CUR-dLV
Supply voltage: ±15 V
THROUGH HOLE (AC/DC) PDF NOMINAL
RMS [A]
SCALING
[A/A]
BANDWIDTH
[kHz]
ACCURACY
[%]
INNER DIAMETER
[mm]
RECOMMENDED
INPUT MODULE
CT-100 Download the PDF here 100 500 2000 0.002 28 TRION(3)-18xx-POWER-4
+ SUB-CUR-02A
CT-200 Download the PDF here 200 1000 1100 0.001 28 TRION(3)-18xx-POWER-4
+ SUB-CUR-02A
CT-400 Download the PDF here 400 1500 800 0.0008 28 TRION(3)-18xx-POWER-4
+ SUB-CUR-1A
CT-500 Download the PDF here 500 750 520 0.00115 38 TRION(3)-18xx-POWER-4
+ SUB-CUR-1A
CT-1000 Download the PDF here 1000 1500 440 0.0012 38 TRION(3)-18xx-POWER-4
+ SUB-CUR-1A
CT-2000CT-2000 Download the PDF here 2000 2000 140 0.0012 70 TRION(3)-18xx-POWER-4
+ SUB-CUR-1A
Supply voltage: ±15 V

DW2-CLAMP-DC-POWER-8

You need to connect more current transducers to a DEWE3-a4 or a DEWE3-M4? Then use the DW2-CLAMP-DC-POWER-8 box for connecting up to eight current clamps to a DEWE3-A4/DEWE3-M4/DEWE2 system.

The box comes with an integrated power supply for up to eight current clamps (±15 V / +9 V), as well as a power supply connector for the instrument (11 to 32 VDC).

Download the PDF hereDownload DW2-CLAMP-DC-POWER-8 Manual





RPM & Angle Sensors

Tape Sensor

  • Optical tape sensor SE-TAPE-01 is a speed and angle sensor that uses black/white tape attached to a rotating part. The reflection is converted into a TTL signal with a bandwidth of 100 kHz.
  • Impulse frequency: max. 100 000 pulses/s

Download the PDF hereDownload Tape Sensor Manual

Tacho Probes

  • These sensors are rpm and angle sensors, where the sensor emits light which is reflected by an object and received by a phototransistor. The rpm and angle information is processed by the software. The output of this sensor is an analog voltage signal.
  • Impulse frequency: 10 to 15 000 pulses/s
  • 2 types available: DB-9 connector (PROBE-01) or BNC and Lemo connector (PROBE-02)

Download the PDF hereDownload Tacho Probe Manual
