DEWE2-M18

Rack-mount data acquisition with DEWE2-M18

KEY FACTS

  • Most importantly, 18 slots for TRION™ modules
  • AC power supply as well as a
  • Solid state disk, 90 MB/s and, of course
  • All connections at the front

Datasheet download

High-Channel Density Data Acquisition System for laboratory bench top

CONNECTIVITY

SOFTWARE

The DEWE2-M18 can use its full potential with the OXYGEN measurement software.

Screens of DEWETRON's measurement software OXYGEN

TRION™ MODULES SELECTION GUIDE

Choose from different multi channel TRION™ modules. The user exchangeable modules provide analog-digital conversion on each channel.

TRION™ modules
Name Channels Sampling [kS/s] / [bit] Sensor supply Voltage input range Current IEPE Bridge [F/H/QU] Thermocouple Charge Resistance, RTD Others
TRION-2402-MULTI
TRION-2402-MULTI
4/8 ISO 204 / 24 0-24 V ±100 CAN, TEDS
TRION-1820-MULTI
TRION-1820-MULTI
4 ISO 2000/24 0-24 V ±100 CAN, CNT, TEDS
TRION-1820-POWER-4
TRION-1820-POWER-4
4 U + 4 I 2000 / 18 +9 V 1000 VRMS Exchangeable current modules (20A, 2A, 0.2A, 5V)
TRION-1600-dLV
TRION-1600-dLV
16 or 32 20 5 V, 12 V ±5 / ±10 2x counter, CAN-bus, 8x DI, 4x DO, RS485, 2x alarm out
TRION-1603-LV-6-L1B
TRION-1603-LV-6-L1B
6 ISO 250 / 16 1-28 V ±100 TEDS
TRION-1603-LV-6-BNC
TRION-1603-LV-6-BNC
6 ISO 250 / 16 - ±100
TRION-1620-LV-6-L1B
TRION-1620-LV-6-L1B
6 ISO 2000 / 24 1-28 V ±100 TEDS
TRION-1620-LV-6-BNC
TRION-1620-LV-6-BNC
6 ISO 2000 / 24 - ±100
TRION-1620-ACC
TRION-1620-ACC
6 ISO 2000 / 24 4 / 8 mA ±100 Tacho
TRION-1802-dLV
TRION-1802-dLV
16 or 32 200 / 100 5 V , 12 V ±5 / ±10 2x counter, CAN-bus, 8x DI, 4x DO, RS485, 2x alarm out
TRION-2402-dACC
TRION-2402-dACC
6/8 DIFF 204 / 24 0.1-24 mA ±100 Tacho, TEDS
TRION-2402-dSTG
TRION-2402-dSTG
6/8 DIFF 204 / 24 0-13 V ±10 TEDS
TRION-2402-V
TRION-2402-V
4/8 ISO 204 / 24 ±1000
TRION-BASE
TRION-BASE
16 DI(O) + 2 CNT 2000 / - 5 V, 12 V DIO, IRIG-B DC, Counter
TRION-TIMING
TRION-TIMING
8 DIO + 1 CNT 2000 / - 5 V, 12 V DIO, IRIG full, GPS 1Hz, Counter
TRION-CNT
TRION-CNT
6 ISO 204 / - 5 V, 12 V Counter
TRION-CAN
TRION-CAN
2/4 ISO 1000 kBit/s 5 V, 12 V CAN
TRION-DI-48
TRION-DI-48
48 ISO 3000 / - 5 V Digital Input
TRION-VGPS
TRION-VGPS
8 DIO + 1 CNT 2000 / - 5 V, 12 V DIO, Counter, GPS 100Hz

DAQP MODULES SELECTION GUIDE

Choose from different DAQP modules which are single channel, dynamic isolation amplifiers with bandwidth up to 300 kHz, an analog ±5 V output and RS-485 interface.

Different external, multichannel CPAD and EPAD modules can be connected and combine analog signal conditioning and A/D converter in an extreme rugged box
Name Channels Sampling [kS/s] / [bit] Interface Voltage range [V] Current Thermocouple Resistance, RTD
CPAD3-V8
CPAD3-V8
8 ISO 100 / 20 CAN 2.0B ± 50
CPAD3-TH8
CPAD3-TH8
8 ISO 100 / 20 CAN 2.0B
CPAD2-V8
CPAD2-V8
8 ISO 12 / 24 CAN 2.0B ± 50
CPAD2-TH8
CPAD2-TH8
8 ISO 12 / 24 CAN 2.0B
CPAD2-RTD8
CPAD2-RTD8
8 ISO 12 / 24 CAN 2.0B
CPAD2-LA8
CPAD2-LA8
8 ISO 12 / 24 CAN 2.0B
